VPOINT TOOLS 3-Flute Spoilboard Surfacing Bits: Replaceable Inserts for Precision

Enhance woodworking precision and efficiency with VPOINT TOOLS’ high-quality 3-flute spoilboard surfacing router bits featuring replaceable inserts. These durable tools deliver smooth, flawless finish…

Contact us

VPOINT TOOLS 3-flute spoilboard surfacing bit with replaceable carbide inserts. Helical cutting geometry delivers clean, tearout-free slab flattening and surface planing on CNC routers, router tables and sled setups.

Specification Value
Cutting diameter 38.1 mm (1-1/2″)
Shank diameter 6.35 mm (1/4″)
Overall length 57 mm
Flutes 3T helical, replaceable inserts
Insert size [待补充：刀片规格，需工厂确认]
Model (catalog) [待补充：确认目录 A018-01 三刃斜齿清底刀与本品对应]
Suitable materials Hardwood, softwood, MDF, plywood, laminate
Grade VP08 (factory-exclusive series)

Why replaceable inserts

When an edge wears or chips, rotate or swap the carbide insert instead of scrapping the whole bit — less downtime, lower tooling cost, consistent finish across batches.

How to use

  • Match the collet to the 6.35 mm shank and tighten securely.
  • For deep flattening, take multiple progressive passes; larger diameter bits need lower RPM.
  • Feed against the rotation direction at a steady, even rate.

Suitable machines

CNC routers, handheld routers, router tables and router sleds.

评价

目前还没有评价

成为第一个“VPOINT TOOLS 3-Flute Spoilboard Surfacing Bits: Replaceable Inserts for Precision” 的评价者

您的邮箱地址不会被公开。 必填项已用 * 标注

VPOINT TOOLS 3 Flute Spoilboard Surfacing Router Bits With Inserts — Application Guide

Reference: Standard router bit specifications. Source: manufacturer product data.

Product Overview

This router bit is precision-engineered for clean, accurate routing in wood and wood-based panels. The carbide cutting edges deliver smooth finishes and long service life.

Key Specifications

  • Material: Tungsten carbide cutting edges on steel body
  • Application: CNC routers, handheld routers, and router tables
  • Compatible Materials: Hardwood, softwood, MDF, plywood, and laminate
  • Cutting Action: Clean, chip-free cuts with minimal tearout

How to Use

  1. Install the bit — Insert the shank into the router collet and tighten securely. Ensure the collet matches the shank diameter.
  2. Set the speed — Use the recommended RPM for your bit diameter and material. Larger bits require slower speeds.
  3. Set cutting depth — Adjust the router depth for your desired cut. For deep cuts, make multiple progressive passes.
  4. Make the cut — Feed the workpiece against the rotation direction at a steady rate. Avoid forcing the bit.
  5. Inspect the result — Check for clean edges and adjust feed rate or speed as needed.

Applications

  • Edge profiling and trimming
  • Grooving, slotting, and dado cuts
  • Template and pattern routing
  • Sign making and decorative woodwork

Safety Precautions

  • Wear safety glasses and hearing protection during routing.
  • Ensure the bit is securely tightened before starting.
  • Keep hands away from the spinning bit at all times.
  • Use push blocks or fences for straight, controlled cuts.
  • Do not exceed the maximum RPM rating of the bit.

Care and Maintenance

  • Inspect cutting edges regularly for wear or chipping.
  • Clean the bit after use to remove resin and pitch buildup.
  • Store in a protective case to prevent edge damage.
  • Replace the bit when cut quality deteriorates.

Content sourced from standard router bit specifications and manufacturer data.
